ITEMS |
· P46A |
· P52A |
|
|
· Capacity |
· Swinging over cross bed |
· 425mm |
· 425mm |
|
· Max.Machining Dia for Shaft |
· ＜160mm |
· ＜160mm |
|
|
· Max.Distance from Chuck to Turret |
· 445mm |
· 395mm |
|
|
· Min.Distance from Chuck to Turret |
· 25mm |
· -25mm |
|
|
· Table Center Height |
· 80mm |
· 80mm |
|
|
· Tool Table Size |
· 650mm*265mm |
· 650mm*265mm |
|
|
· T-Slot Centers |
· 3Slots-65mm-M10 |
· 3Slots-65mm-M10 |
|
|
· Spindle |
· Spindle Noise |
· A2-5 |
· A2-6 |
|
· Spindle Through Hole |
· ⌀56mm |
· ⌀66mm |
|
|
· Spindle Speed (RPM) |
· 0-6000r/min |
· 0-4500r/min |
|
|
· Spindle Center Height (Above Datum) |
· 1080mm |
· 1080mm |
|
|
· Feeding Travel |
· X-Axis Travel Length |
· 900mm |
· 900mm |
|
· Z-Axis Travel Length |
420mm |
420mm |
|
|
· Feeding Speed |
· X-Axis Rapid Traverse Speed |
· ≤ 30m/min |
· ≤ 30m/min |
|
Z-Axis Rapid Traverse Speed |
≤ 30m/min |
≤ 30m/min |
|
